- General Information
- Manufacturer
- Eaton Corporation
- Manufacturer Website Address
- http://www.eaton.com
- Brand Name
- Eaton
- Product Type
- Battery Unit
Backup Battery Module Gives Your Compatible Eaton UPS System Extended Runtime
The 9PXEBM240RTG2 offers extended battery runtime when used in conjunction with Eaton's 9PX8KG2, 9PX8KTF5G2, 9PX11KG2, 9PX11KTF11G2, 9PX11KTF11MG2, and 9PX11KTF5G2 9PX UPS systems. It can also be daisy-chained for a maximum of 12 auto-detected battery packs to deliver even longer extended-run operation. Heavy-gauge cabling with high-current DC connectors is included for safe, simple installation.
Supports 3U Rack or Tower Installation
This backup battery pack's multi-use form factor supports mounting in 3U of space in an EIA-standard 19-inch rack using the included 4-post rail kit. You can also adapt it for tower installation using the included support stands. For installation in 2-post racks, one RK2PC mounting kit (sold separately) is required for each UPS, EBM, PPDM or transformer.
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Battery Characteristics
- Valve-regulated/User Replaceable
- Battery Chemistry
- Lead Acid
- Hot Swappable
- Yes
- Output Voltage
- 240 V DC
- Battery Size
- Proprietary Battery Size
- Environmental Conditions
- Minimum Operating Temperature
- 32°F (0°C)
- Maximum Operating Temperature
- 104°F (40°C)
- Physical Characteristics
- Height
- 5.1"
- Width
- 17.3"
- Depth
- 26.4"
- Weight (Approximate)
- 143 lb
- Miscellaneous
- Package Contents
- 9PXEBM240RTG2 Battery Unit
- External Battery Cable, 1 ft. (0.3 m)
- Tower Support Stands
- Rack-mounting Hardware
- Quick Start Guide
- Compatibility
Eaton's 9PX G2 UPS Systems:
- 9PX8KG2
- 9PX8KTF5G2
- 9PX11KG2
- 9PX11KTF11G2
- 9PX11KTF11MG2
- 9PX11KTF5G2
- Certifications & Standards
- NOM (Mexico)
- cUL Listed
- EN 62040-2
- CE (Europe)
- FCC (USA)
- FCC Part 15 Class A (USA)
- Energy Star
- Yes
- Country of Origin
- Philippines
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
